Specifications

Conformable and flexible hybrid material. Designed for car wrapping (the smooth or medium curved surface).

The thickness of the film: 0.10mm
The thickness of film with release liner: 0.26mm

Type of film: Polymeric vinyl film (silver coating) with new air release channels

Series: 180 series
Glue: Henkel solvent-based adhesive
Release liner: White silicone-coated paper with a double-sided polyethylene coating
Storing period: 3 years if stored in +10°С to +20°С, relative humidity 50%, in original package, away from direct sunlight, clean and dry place
Indoor life: 4 years when followed rules of application and use
Outdoor life: 2 years when followed rules of application and use
Dimensional stability: shrinkage less than 0,20%
Plastification: between 23%-31%
Breaking Strength: 27.7 N/10mm (Average) Test Method: ASTM D3759/D3759M-05
7.4 N/10mm (Average) Test Method: ASTM D3330/D3330-04
Light Ageing in UV Exposure:
Test Method: ASTM D4329-13 Cycle A & ISO 105-A02:1993/Cor.2:2005, Test result: 4-5
Exposure cycle: ASTM D4329-13 cycle A, Lamp type: UVA-340
8h UV at (60±2.5)℃ BPT, 0.89 W/ (m2•nm)@340nm, 4h condensation at (50±2.5)℃ BPT, Exposure duration: 48h
Package: Roll width 152 cm, length 18 m, weight 13 kg
